AMD Ryzen 9000X3D rumored to reverse the 3D stacking hierarchy — the L3 cache block allegedly sits below the CCDs

News
By
Published

So that's where the higher clock speeds and better thermals stem from.

Ryzen CPU with 3D V-Cache
(Image credit: AMD)
25

In two weeks, AMD will introduce its Ryzen 9000X3D chips, which will rival the best CPUs on the market. Hardware leaker HXL on X has clarified, to some extent, the architectural differences between the first and second generations and why AMD can achieve better thermals and higher clock speeds with Ryzen 9000X3D. It is claimed that AMD is reversing its 3D die-stacking structure, with the SRAM block now placed beneath the CCDs.

When AMD first launched its Ryzen 5000X3D chips, the concept was to stack a block of L3 cache atop the CCDs. A large issue with this model was heat dissipation due to using extra silicon over the CCDs for structural integrity. This thermal constraint also restricted AMD from bumping the clock speeds on these processors. However, that seems to be addressed with Ryzen 9000X3D, as the CCD reportedly sits atop the cache die. If true, AMD's new design will genuinely be an engineering marvel - from both architectural and packaging standpoints.

Latest Videos FromTom's Hardware
Hassam Nasir
Hassam Nasir
Contributing Writer

Hassam Nasir is a die-hard hardware enthusiast with years of experience as a tech editor and writer, focusing on detailed CPU comparisons and general hardware news. When he’s not working, you’ll find him bending tubes for his ever-evolving custom water-loop gaming rig or benchmarking the latest CPUs and GPUs just for fun.
